▼Core Functions
Triple-Mode Flexibility
Ultra-Low Freezing: -30℃~-18℃ for bulk meat/seafood storage
Precision Refrigeration: 0℃~12℃ for full-container preservation of produce, flowers, or pharmaceuticals
Multi-Zone Configuration (customizable): Up to 3 independent temperature zones
Industrial Cooling System
Dual-compressor redundancy design for 24/7 continuous operation
Smart Management Platform
10.1" touchscreen + cloud data management (90-day historical records)
▸ External Dimensions: 12.192m(L) × 2.438m(W) × 2.896m(H)
▸ Effective Volume: 67.5m³ (stores 40-45 tons of goods)
▸ Cooling Capacity: 2×15HP DC Inverter compressors (Bitzer Technology)
▸ Daily Power Consumption: ≤125kWh (ambient temperature ≤32℃)
▸ Storage System: Optional heavy-duty rail shelves (800kg/layer capacity)
120% Higher Storage Efficiency
18% lower energy consumption per unit vs. 20ft models
Enterprise-Grade Security
Biometric fingerprint lock + mechanical key + explosion-proof lighting
Scalable Networking
Supports multi-container clusters for distributed cold chain networks
Rapid Temperature Recovery
Restores set temperature within 15 minutes after door opening (30% faster than 20ft)
Full Lifecycle Support
5-year compressor warranty + global spare parts network
Feature | 40ft Container Cold Storage | 20ft Container Cold Storage |
Max Capacity | 45 tons | 22 tons |
Ideal Applications | Ports/Central Kitchens/Plants | Farms/Small Distribution Centers |
Monthly Op Cost* | 2,800 2,800 3,500 | 1,200 1,200 1,800 |
Installation Space | 6m×15m | 3m×8m |
Power Requirements: 480V 3-phase (North America) / 380V 100A (Other regions)
Floor Load Capacity: ≥5 tons/m² required
Transport Compliance: Oversize permits needed for inland logistics
Pre-Cooling: 24-hour pre-cooling mandatory for initial use
Unit Standardization: Metric-first with clear imperial conversions in tooltips (recommended for landing page implementation)
Voltage Compatibility: Covers both North American (480V) and international standards (380V)
Certifications: CE/UL/FDA/HACCP referenced (globally recognized)
Terminology: "Pallets" instead of regional terms like "trays"
Cost Transparency: USD-based estimates with clear footnote (*Based on $0.18/kWh avg. Rates vary by region)
Safety Protocols: Biometric access aligns with ISO 22000 food safety requirements
Climate Resilience: -30℃~+50℃ operational range covers most global zones
