▼Core Functions

Freezing/Refrigeration Dual Modes

Freezing Mode: -25℃~-18℃ professional-grade storage for long-term preservation of meat and seafood

Refrigeration Mode: 0℃~10℃ precision freshness system for fruits, vegetables, flowers, and pharmaceuticals

Smart Temperature Control
Industrial-grade cooling units with IOT remote monitoring (±1℃ temperature stability)

Dual-Zone Conversion
Patented partition design for simultaneous freezing/refrigeration zones (customizable)

Emergency Backup Power
Built-in 8-hour UPS ensures product safety during power outages

▼Technical Specifications

▸ External Dimensions: 6.058m(L) × 2.438m(W) × 2.591m(H)
▸ Effective Volume: 28.3m³ (stores 18-22 tons of goods)
▸ Refrigerant: Eco-friendly R404A/R32/R410 etc.
▸ Insulation: 150mm polyurethane sandwich panels (EU food-grade standard)
▸ Daily Power Consumption: ≤58kWh (ambient temperature ≤32℃)

▼6 Key Advantages

Rapid Deployment
Pre-assembled modular structure, operational within 72 hours
Energy Efficiency Certified
Excellent performance compressor reduces energy use by 35%
Extreme Climate Adaptability
Stable performance in -30℃~+50℃ environments (polar kits optional)
Portability
Standard container corner fittings for seamless land/sea logistics
Smart IoT Integration
4G/WiFi remote monitoring with real-time alerts (temperature, humidity, door status)
Global Compliance
FDA/HACCP/CE/UL certified for food safety and international standards

▼Important Notes

Installation Requirements: Level 3m×8m site + 380V industrial power supply
Loading Guidelines: Maintain ≥15cm ventilation gap from inner walls
Maintenance: Quarterly condenser cleaning recommended
Climate Adaptation: Enhanced cooling units required for tropical region
